Lucent Technologies MERLIN LEGEND Release 6.1 System Programming

MERLIN LEGEND Communications System Release 6.1
System Programming Guide 555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-94Lines and Trunks
3
● Single Line Procedure
Console Display/Instructions Additional Information PC
! Specify entry mode.
Select
(QWU\0RGH.

! Enter the line/trunk number for the pool.
! Assign or remove the line/trunk from the pool.
Select
(QWHU or

'HOHWH.

You may continue to assign or remove additional
lines/trunks from the pool by repeating Steps 2
and 3.
! Return to the System Programming menu.
Select
([LW twice.

◆ Block Procedure
Console Display/Instructions Additional Information PC
! Specify the block of 20 lines associated with the 20 line buttons
on the system programming console.
Select
/LQHV 
/LQHV 
/LQHV 
/LQHV 
! Assign the appropriate lines/trunks to the pool.
Toggle the red LED on or off as required.
On = trunk is assigned to specified pool
Off = trunk is not assigned to specified pool
! Return to the System Programming menu.
Select
([LW twice.

3RRO YYY 
xxx = pool dial-out code entered in Step 3
(QWHUOLQHWUXQNQXPEHU
Dial or type:
Ã
'HOHWH
Trunk number [ nnn ]
%DFNVSDFH
Slot and port number [ sspp ]
([LW (QWHU
Logical ID number #[ nnn ]
