MERLIN LEGEND Communications System Release 6.1
System Programming Guide
555-661-111
Issue 1
August 1998
Programming Basics
Page 1-10System Programming Console
1
Console and DSS Lights 1
The red and green lights (LEDs) next to each of the 20 line buttons on the
MLX-20L console show the status of the line/trunk options. LEDs on the DSS
show the status of features programmed on extensions. See Appendix C, “LED
Displays,” for more information.
Console Lights 1
The green and red LEDs next to each button on the console display the status of
the line/trunk option that is being programmed. For example, when you select
3RROV from the Lines Trunks menu, the red LED is off if the selected line is not in
a pool and on if the line is in a pool. Appendix C, “LED Displays,” provides a table
that shows the default LED status for line/trunk options.
DSS Lights 1
The lights on the DSS (if one is attached to the console) show the status of
features being programmed on the extensions. When you select a feature from a
menu, the red LED next to the DSS button is on, off, or flashing, depending on
whether the feature is already programmed on the corresponding extension. For
example, when you select 7ROO5HVWULFW from the Restrictions menu, the red
LED next to the DSS button lights for each toll-restricted extension. Appendix C,
“LED Displays,” provides a table that shows the default DSS status of LEDs for
system features.
