Lucent Technologies MERLIN LEGEND Release 6.1 System Programming

MERLIN LEGEND Communications System Release 6.1
System Programming Guide 555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-130DS1 Facilities
3
Console/Display Instructions Additional Information PC
! Save your entry.
Select
(QWHU.

! Return to the System Programming menu.
Select
([LW twice.

If you are using PRI Facilities, go to
“Zero Code Suppression.”
Zero Code Suppression 3
Use this procedure to specify zero code suppression for the 100D module as AMI
zero code suppression (AMI-ZCS) or bipolar eight zero suppression (B8ZS). Your
selection must match the suppression at the far end of the DS1 facility.
NOTE:NOTE:NOTE:
In Release 6.0 and later systems, use bipolar eight zero suppression
(B8ZS) for tandem PRI trunks.
Summary: Zero Code Suppression 3
Programmable by System Manager
Mode All
Idle Condition 100D module idle
Planning Form Form 3b, Incoming Trunks: DS1 Connectivity (100D module)
Factory Setting AMI-ZCS
Valid Entries AMI-ZCS, B8ZS
Inspect No
Copy Option No
Console Procedure
/LQHV7UXQNV→/6*6'6→Dial slot no.→ (QWHU→
6XSSUHVVLRQ→$0,=&6 or %=6→ (QWHU→([LW→([LW
PC Procedure

→→Type slot no.→→→
or
→
→→
