Lucent Technologies MERLIN LEGEND Release 6.1 System Programming

MERLIN LEGEND Communications System Release 6.1
System Programming Guide 555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-151Tie Trunks
3
◆ Block Procedure
Console/Display Instructions Additional Information PC
! Specify the block of 20 lines associated with the 20 line buttons on the
system programming console.
Select
/LQHV 
/LQHV 
/LQHV 
/LQHV 
! Specify touch-tone or rotary signaling for each line/trunk.
Toggle the green LED on or off as required.
On = touch-tone
Off = rotary
! Return to the System Programming menu.
Select
([LW three times.

Tie Trunk Dial Tone 3
Use this procedure to specify whether the system provides dial tone for people
calling in on a tie trunk. The settings are remote (system provides dial tone) and
local (system does not provide dial tone).
Summary: Tie Trunk Dial Tone 3
Programmable by System Manager
Mode All
Idle Condition Not required
Planning Form Form 3c, Incoming Trunks: Tie
Factory Setting Remote
Valid Entries Remote, Local
Inspect Yes
Copy Option Yes
Console Procedure To program a single line/trunk:
/LQHV7UXQNV→7,(/LQHV→'LDOWRQH→(QWU\0RGH→
Dial trunk no.→(QWHU or 'HOHWH→([LW→([LW→([LW
To program a block of lines/trunks:
/LQHV7UXQNV→7,(/LQHV→'LDOWRQH→Select block of lines/
trunks
→Toggle LED On/Off→([LW→([LW→([LW
