Programming Procedures
Page 3-209PRI Facilities
3
Telephone Number to Send 3
Use this procedure to assign the telephone number to send to the network when
outgoing calls are made on an ISDN line. If the person being called subscribes to
an automatic number identification service, the number indicates who is calling.
The number assigned to each channel does not have to be unique because it is
not used for routing.
The telephone number sent to the network can be the one of the following:
■ The extension number assigned to the calling telephone (Select
([WHQVLRQ2QO\ in Step 4)
■ The extension number substituted into the lower order digits of a
systemwide base number (Select %DVH1XPEHUZLWK([W in Step 4)
■ The facility-based line telephone number (Select /LQH7HOHSKRQH
1XPEHU in Step 4)
NOTE:NOTE:NOTE:
Only one base number is supported per system. In systems having non-
uniform extension numbers, for example, where there are some 3-digit
extension numbers and some 4-digit extension numbers, one base number
may not be sufficient to represent all the outside telephone numbers of all
extensions.
Summary: Telephone Number to Send 3
Programmable by System Manager
Mode All
Idle Condition Not required
Planning Form Form 3b, Incoming Trunks: DS1 Connectivity (100D module)
Factory Setting No digits are assigned
Valid Entries Up to 12 digits (any combination of 0 to 9)
Inspect No
Copy Option No
Console Procedure
/LQHV7UXQNV→35,→1XPEU7R6HQG→Specify type of no.→
(QWHU→Drop→Dial base no.→(QWHU→Dial line no.→
(QWHU→Drop→Dial telephone no.→(QWHU→([LW→([LW
PC Procedure

→→→Specify type of no.→→7
+
I→
Type base no.→→7
+
I→Type telephone no.→
→→
