MERLIN LEGEND Communications System Release 6.1
System Programming Guide
555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-295Auxiliary Equipment
3
Console Display/Instructions Additional Information PC
! Enter the line/trunk.
! Assign or remove the line/trunk assignment.
Select
(QWHU or
'HOHWH.
! Return to the System Programming menu.
Select
([LW.
Fax Machines 3
Use this procedure to add a fax machine by assigning the extension jack used to
connect the fax machine. To remove a fax machine and free the extension jack for
another use, you must remove the extension jack assignment.
In addition, you can specify the extensions to receive a message-waiting
indication (MWI) when a fax transmission is received, and specify the length of
time before the system registers that a fax has arrived and sends the message-
waiting indication.
NOTE:NOTE:NOTE:
Do not use this procedure for fax machines connected to analog multiline
telephones with a General Purpose Adapter (GPA). In a GPA configuration,
features cannot be assigned to the fax independently of the telephone.
A maximum of 16 fax machines can have the Fax Message Waiting feature.
Additional fax machines (more than 16) can be installed, but these machines
cannot have this feature.
You can specify up to four telephones to receive the message-waiting indication
when a fax transmission is received. Note that fax machines can only send and
not receive message-waiting indications.
/RXGVSHDNHU3DJH
If the line/trunk appears on the screen and
(QWHUORXGVSHDNHUSJOLQH
you want to remove the loudspeaker
assignment, go to Step 4.
'HOHWH
Dial or type:
Ã
%DFNVSDFH
Trunk number [
nnn
]
([LW (QWHU
Slot and port number [
sspp
]
Logical ID number
[
nnn
]
To Next Page
