MERLIN LEGEND Communications System Release 6.1
System Programming Guide
555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-317Optional Extension Features
3
Pool Dial-Out Code 3
Use this procedure to allow or restrict dialing pool dial-out codes and the placing
of calls on specific line/trunk pools. Beginning with Release 3.1, the factory
settings restrict all extensions from dialing any line/trunk pool dial-out code.
NOTE:NOTE:NOTE:
Prior to Release 3.1, the factory settings allow all extensions to dial any
line/trunk pool dial-out code. Entering a pool dial-out code and then deleting
that code restricts the user from using the pool associated with the entered
code.
!
SECURITY ALERT:
In Release 6.0 and later systems (Hybrid/PBX mode only), do not allow dial
access to pools of non-local tie or PRI tandem trunks. When callers in your
system need to use these pools for outside calls, use ARS to direct the calls
to these pools. Callers in your system use normal inside calling procedures
to reach extensions on private networked systems.
Summary: Pool Dial-Out Code 3
Programmable by System Manager
Mode Hybrid/PBX
Idle Condition Extension idle
Planning Form Form 4b, Analog Multiline Telephone
Form 4d, MLX Telephone
Form 4e, MFM Adjunct: MLX Telephone
Form 4f, Tip/Ring Equipment
Form 5a, Direct-Line Console (DLC): Analog
Form 5b, Direct-Line Console (DLC): Digital
Form 5c, MFM Adjunct (DLC): Digital
Form 5d, Queued Call Console (QCC)
Data Form 1a, Modem Data Workstation
Data Form 1b, ISDN Terminal Adapter Data Workstation
Factory Setting Main pool: 70; All other pools: 890 to 899. All telephones are
restricted from dialing any pool dial-out code.
Valid Entries Pool numbers
Inspect Yes
Copy Option No
Console Procedure
([WHQVLRQV→'LDO2XW&G→Dial ext. no.→(QWHU→ Dial pool
dial-out code
→(QWHU→([LW→([LW
PC Procedure

→→Type ext. no.→→Type pool dial-out code→
→→
