Lucent Technologies MERLIN LEGEND Release 6.1 System Programming

MERLIN LEGEND Communications System Release 6.1
System Programming Guide 555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-437Optional Group Calling Features
3
Group Calling Calls-In-Queue Alarm Thresholds 3
Use this procedure to specify the number of unanswered calls that wait in the
calling group queue before group members are notified with either an external
alert (an external alert is turned on when the third threshold is met) or a light on
the telephone. Group members are notified when the number of calls waiting in
the queue is equal to or greater than the programmed thresholds as follows:
■ First Threshold, flashing light
■ Second Threshold, winking light
■ Third Threshold, solid light
NOTE:NOTE:NOTE:
To configure only one threshold, set
all thresholds to the same number.
The LED states are off and on. To configure only two thresholds, set two of
the thresholds to be the same number.
Summary: Group Calling Calls-In-Queue Alarm
Thresholds 3
Programmable by System Manager
Mode All
Idle Condition Not required
Planning Form Form 7d, Group Calling
Factory Settings 1 call, for all Thresholds
Valid Entries 1 to 99
Inspect No
Copy Option No
Console Procedure
([WHQVLRQV→More→*US&DOOLQJ→4XHXH$ODUP→
Dial calling group ext. no.→(QWHU→$ODUP7KUHVKROG or
$ODUP7KUHVKROGor $ODUP7KUHVKROG
→Drop→
Dial no. of calls→(QWHU→([LW→([LW
PC Procedure

→→→→Type calling group ext. no.→
→7
+
I→%
or
%
or
→Type no. of calls→
→→
