MERLIN LEGEND Communications System Release 6.1
System Programming Guide
555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-569Uniform Dial Plan Routing
3
UDP Facility Restriction Level 3
Use this procedure to assign a Facility Restriction Level (FRL) to each UDP route.
The FRL ranges from 0 (least restrictive) to 6 (most restrictive) and prevents users
from accessing the route. The FRL assigned to extensions and remote access
users is the opposite of the FRL assigned to routes, with 0 being most restrictive
FRL, and 6 the least restrictive. A call will succeed if the extension’s (or remote
access) FRL is greater than or equal to the facility’s FRL.
FRLs assigned to extensions (or remote access) apply not only to ARS calls but
also to calls for non-local dial plan extensions connected by private trunks to your
local system. For this reason, use care in assigning FRLs both to extensions and
to UDP routes. For example, if a user must be restricted from toll calls on your
local system, you may need to plan UDP routes’ FRLs to be unrestricted, so that
the user can reach necessary non-local dial plan extensions. For information
about assigning FRLs to extensions, see “ARS Restriction Level for Extensions”
on page 3–327.
NOTES:
1. UDP pool routes must be programmed before you assign Facility
Restriction Levels to those routes.
2. Extension outward and toll calling restrictions are removed when a user
dials a non-local dial plan extension. However, FRL extension
restrictions remain in effect but are not sent with the call.
3. If you have Centralized Voice Messaging, program an FRL of 0 for the
routes used to send calls to Centralized Voice Messaging. See the
Network Reference
for additional information.
Summary: UDP Route Facility Restriction Level 3
Programmable by System Manager
Mode Hybrid/PBX
Idle Condition Not required
Planning Form Non-Local Dial Plan Administration Form in the Installation
Specification
Factory Setting 3
Valid Entries 0 to 6
Inspect No
Copy Option No
Console Procedure
7DEOHV→8'35RXWLQJ→Dial pattern no.→(QWHU→
Dial route no.→(QWHU→)5/→Dial restriction level→
(QWHU→([LW→([LW→([LW→([LW
PC Procedure
→→Enter pattern no.→→Type route no.→
→→Type restriction level→→→
→→
To Next Page
