Lucent Technologies MERLIN LEGEND Release 6.1 System Programming

MERLIN LEGEND Communications System Release 6.1
System Programming Guide 555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-579Uniform Dial Plan Routing
3
Console/Display Instructions Additional Information PC
!Continue to specify other digits for another route in the current pattern or
go to Step 11.
Select
1H[W.

Return to Step 8. The next route number
is displayed on Line 1.
!Save your entry.
Select
(QWHU.

!Return to the System Programming menu.
Select
([LW four times.

UDP Voice and/or Data Routing 3
Use this procedure to route voice, data, or voice and data. For UDP routing, the
voice/data specification is used in conjunction with PRI tandem trunks. See “PRI
Facilities” on page 3–183 for more information. When using Fractional-T1 tandem
trunks, each channel on the trunk can be used for either voice or data, but not for
voice/data. See “DS1 Facilities” on page 3–105
for more information.
Voice/data routes can be associated with any UDP pattern.
Summary: UDP Voice and/or Data Routing 3
Programmable by System Manager
Mode Hybrid/PBX
Idle Condition Not required
Planning Form Non-Local Dial Plan Administration Form in the Installation
Specification
Factory Setting Voice/Data
Valid Entries Voice Only, Data Only, Voice/Data
Inspect No
Copy Option No
Console Procedure
7DEOHV→8'35RXWLQJ→Dial pattern no.→(QWHU→
Dial route no.→(QWHU→'DWD→Select capability→(QWHU→
([LW→([LW→ ([LW→([LW
PC Procedure

→→Type pattern no.→→Type route no.→
→→Select capability→→→→→
