Lucent Technologies MERLIN LEGEND Release 6.1 System Programming

MERLIN LEGEND Communications System Release 6.1
System Programming Guide 555-661-111
Issue 1
August 1998
Programming Procedures
Page 3-619Data Features
3
Analog Multiline Telephones at Data
Workstations 3
Use this procedure to dedicate a pair of extension jacks to provide the voice and
data to an analog data workstation.
The extension number associated with the first (odd-numbered) extension jack in
the pair is the telephone’s extension number. The extension number for the
second (even-numbered) extension jack is dedicated to Data.
Calls cannot be placed to the extension jack reserved for data.
Voice Announce to Busy must be disabled at data workstations.
When you select
(QWHU after entering the voice extension number in the data
entry screen, the system automatically assigns the data extension.
Use the Inspect feature to verify extension pairs.
Summary: Analog Multiline Telephones at Data
Workstations 3
Programmable by System Manager
Mode All
Idle Condition System idle
Planning Form Form 2a, System Numbering: Extension Jacks
Form 4b, Analog Multiline Telephone
Form 5a, Direct-Line Console (DLC): Analog Data
Data Form 2a, Analog Data Workstation
Factory Setting Not applicable
Valid Entries Extension numbers of analog sets
Inspect Yes
Copy Option Yes
Console Procedure More
→'DWD→9RLFH/'DWD→Dial ext. no.→(QWHU→([LW
PC Procedure

→→→Type ext. no.→→
