Table 7.6 O-Ring Boss (ORB) Hydraulic Fittings – Adjustable
SAE Dash Size
Thread Size (in.)
Torque Value
6
Nm
lbf·ft (*lbf·in)
-2 5/16–24 6–7 *53–62
-3 3/8–24 12–13 *106–115
-4 7/16–20 19–21 14–15
-5 1/2–20 21–33 15– 24
-6 9/16–18 26–29 19–21
-8 3/4–16 46–50 34– 37
-10 7/8–14 75–82 55–60
-12 1 1/16–12 120–132 88–97
-14 1 3/8 –12 153–168 113–124
-16 1 5/16–12 176–193 130–142
-20 1 5/8 –12 221–243 163–179
-24 1 7/8 –12 270–298 199–220
-32 2 1/2 –12 332–365 245–269
REFERENCE
6. Torque values shown are based on lubricated connections as in reassembly.
