214880 13 Revision A
Chapter 2: Product Overview
2.1 Specifications
NOTE:
Specifications and design are subject to change without notice or obligation to revise previously sold units.
Frame and Structure
Width (transport) 5027 mm (198 in.)
Weight: base machine with steel conditioner
2156 kg (4750 lb.)
Compatible windrower
MacDon M1240
Lighting Left and right turn signals
Manual storage
Plastic case on header — Left header support
deflector
Cutterbar
Number of cutting discs
Ten
Blades per disc Two 18 degrees bevel down
Disc speed (full engine speed)
2500 rpm
Blade max tip speed
80.5 m/s (180 mph)
Effective cutting width
4942 mm (16 ft. 2 in.)
Minimum Cutting height
27 mm (1 1/16 in.)
Cutting angle range 0–8 degrees below horizontal
Adjustable shoes Standard
Gear train protection
Shearpin (safecut)
Converging Drums
Four-drum type
Drives
Hydraulic motor Piston type into 90-degree gearbox
Cutterbar
Direct drive through 90-degree gearbox and
universal shaft
Conditioner drive
Belt drive (4HB) from 90-degree gearbox to
conditioner
Conditioner roll timing Timing gearbox
