214880 23 Revision A
Figure 3.6: Safety Prop
4. Disengage safety props on both lift cylinders as follows:
NOTE:
If safety prop will not disengage, raise header to release
the prop.
a. Turn lever (A) away from header to raise safety prop
until lever locks into vertical position.
b. Repeat for opposite cylinder.
CAUTION
Check to be sure all bystanders have cleared the area.
5. Start the engine, choose a level area, and lower header to
the ground. Shut down the engine and remove the key
from the ignition.
OPERATION
