Spare parts required for maintenance
11.2 Lighting
11 - 2 3 302 364 en Maintenance manual
GMK 4100L-1
25.11.2016
Installation point GROVE part
number
Designation Power (W)
CARRIER LIGHTING:
Front spotlights:
(integrated in the bumper)
– Daytime driving light (left) 04163680 LED
– Daytime driving light (right) 04136679 LED
– Low-beam + full-beam headlights 03134828 H7 24V 70
– Low-beam + full-beam headlights (USA) 03143584 H9 12V 65
– Indicator light 03327578 PY21W 24V 21
– Parking light (in the direction
indicator
li
ght)
03140908 LED
– Yellow side marker light 03320937 LED
Front, side indicator lights:
(under the access ladder to the driver's cab)
– Indicator light 03327578 PY21W 24V 21
Tail lights:
(at the rear of the chassis)
– Marker light 03137450 R5W 24V 5
– Number plate light 03137450 R5W 24V 5
– Rear light 03137450 R5W 24V 5
– Brake light 03328445 P21W 24V 21
– Indicator light 03327578 8GA 006841241 24 V / 21 W
– Fog tail light 03328445 P21W 24V 21
– Reverse light 03328445 P21W 24V 21
Licence plate lamp, external:
(at the rear of the chassis)
– LED licence plate light 04163112 LED
Yellow side marker lights:
(at the sides, along the chassis)
– Side marker light 03140042 LED
White rear marker lights:
(at the rear of the chassis)
– Left marker light 03327625 LED
– Right marker light 03327626 LED
