Spare parts required for maintenance
11.2 Lighting
25.11.2016
Maintenance manual 3 302 364 en 11 - 3
GMK 4100L-1
White front marker lights:
(at the top on the driver's cab)
– Marker light 01207144 R10W 24V
Outrigger beam spotlights:
(above the front and rear outrigger beams)
– LED spotlight; complete 03143786 M70 LED
Yellow rotating beacon:
(on the driver's cab)
– Rotating beacon; complete 04156048
Inside light:
(in the driver's cab)
– Cab light 03135111 24V 24V / 15W
– Reading light 03135111 24V 24V / 15W
Dashboard light:
(in the cab; socket 12V)
– Filament lamp 04159964 Xenon 12V / 6W
s
Installation point GROVE part
number
Designation Power (W)
