Spare parts required for maintenance
11.2 Lighting
11 - 4 3 302 364 en Maintenance manual
GMK 4100L-1
25.11.2016
SUPERSTRUCTURE LIGHTING:
Marker lights, yellow:
(left and right on the main boom head)
– Marker light; complete 03329569 LED
Red rear marker lights:
(on the turntable)
– Marker light; complete 03329492 LED
Yellow rotating beacon:
(on the turntable)
– Rotating beacon; complete 04156048
Inside light:
(in the crane cab)
– Cab light 00550434 K 24V 10
– Reading light 00550434 K 24V 10
Spotlight, angular-shaped, permanently installed:
(at the front of the crane cab)
– Filament lamp 01573349 H3 24V 70
Spotlight, electrically adjustable:
(at the front of the main boom)
– Halogen bulb 03142726 8GS009028001
35
Installation point GROVE part
number
Designation Power (W)
