TMS800E SERVICE MANUAL ELECTRIC SYSTEM

GROVE

Published 01-29-2014, Control # 496-00

FIGURE 3-3

Carrier Cab

Item Description

1 Fuse Panel

2 K1 and K2 Relays

3 Terminal Strip (2)

4 Buzzer

5 Crane USB Diagnostics Connector

6 Ground Tab

FIGURE 3-4

Reference Only
