ELECTRIC SYSTEM TMS800E SERVICE MANUAL

3-4

Published 01-29-2014, Control # 496-00

FIGURE 3-2

Superstructure Cab

Superstructure Right Side

Superstructure Left Side

Item Description

1 Right Side Control Module

2 CL-306 Control Module

Item Description

3 CL-305 Control Module

4 IO Module

Reference Only
