5-9
TMS800E SERVICE MANUAL HOIST AND COUNTERWEIGHT
5
GROVE
Published 01-29-2014, Control # 496-00
a. With one layer of cable on the hoist drum, adjust the
bolts on the front of each side plate (that push
against each arm) so the roller applies pressure on
the layer of cable, and does not interfere with filler/
riser protrusions on the hoist drum flanges. Tighten
jam nuts to secure setting.
b. With a full drum of cable, the adjusting spring length
from eye to eye should not exceed 25.7 cm (10.12
in). Adjust rods as necessary and tighten jam nuts to
secure this setting.
Complete Assembly
Removal
1. Remove all tension from the springs on each side by
loosening the nuts and jam nuts.
2. Support the weight of the assembly and remove the two
bolts and washers securing each side plate to the hoist.
Remove the idler drum and cable follower assembly
from the hoist.
3. If necessary to completely disassemble or remove any
part of the assembly, refer to the applicable paragraphs
in this Sub-section.
Installation
1. Position the idler drum and cable roller assembly on the
hoist and secure each side plate to the hoist with two
bolts and washers.
2. Adjust the tension on the cable follower. Refer to
instructions in paragraph titled CABLE FOLLOWER -
Assembly and Installation in this Sub-Section.
