INTRODUCTION TMS800E SERVICE MANUAL
Table 1-1: Axle Weight Distribution
DESCRIPTION
CG to CL
REAR BOGIE
cm (in)
WEIGHT
kg (lb)
FRONT AXLE
kg (lb)
REAR AXLE
kg (lb)
Maximum Tire & Wheel Loads Allowed 22317 (49200) 27216 (60000)
Maximum Axle Loads Allowed 23224 (51200) 27216 (60000)
Carrier 8 x 4 x 4 (w/O/R Beams) 294.79 (116.06) 20158 (44441) 10568 (23299) 9590 (21142)
Superstructure
(w/main & aux. hoists with cable)
-92.79 (-36.53) 6417 (14148) -1059 (-2335) 7477 (16483)
Boom Assembly w/(2/4) sheaves, RCL,
pivot pins
478.66 (188.45) 9354 (20621) 7962 (17554) 1391 (3067)
Lift Cylinder & Lower Shaft 314.73 (123.91) 1213 (2674) 679 (1497) 534 (1177)
Add: Aux boom nose, installed 1170.53 (460.84) 59 (130) 123 (271) -64 (-141)
Complete Basic Machine
TMS800E Carrier and S/S
• 4-Section boom (13 - 39 m/41 - 128 ft)
• 8 x 4 x 4 chassis; Cummins ISX 11.9
2013 Engine
• Front and rear axles; 445/65R22.5
front & 315/80R22.5 rear Goodyear
tires
• Main hoist w/183 m (600 ft) of 3/4”
cable
• Aux hoist w/185 m (607 ft) of 3/4” cable
• Full fuel and hydraulic oil
• Steel Outrigger Floats
274.78 (108.18) 37142 (81884) 18150 (40014) 18992 (41870)
Jibs
10.1 to 17.1 m (33 to 56 ft)
Folding Jib w/Mast
640.00 (251.97) 1200 (2645) 1365 (3010) -166 (-365)
Add: 10.1 m (33 ft) Fixed Jib w/mast 718.85 (283.01) 829 (1827) 1060 (2336) -231 (-509)
Jib Carrier Brackets (Bolt On) 499.82 (196.78) 159 (351) 142 (312) 18 (39)
Aux Boom Nose 1170.53 (460.84) 59 (130) 123 (271) -64 (-141)
Add: 6.1 m (20 ft) Boom Ext. w/RCL
(pinned to boom nose)
875 (397)
Counterweights
1814 kg (4000 lb) counterweight on S/S
(top piece with pins)
-298.73 (-117.61) 1822 (4016) -968 (-2134) 2790 (6150)
Add: 1814 kg (4000 lb) counterweight on
S/S (with pins)
-298.73 (-117.61) 1820 (4013) -967 (-2132) 2787 (6145)
1814 kg (4000 lb) counterweight on
carrier deck (with pins)
473.43 (186.39) 1820 (4013) 1533 (3379) 288 (634)
Add: 1814 kg (4000 lb) counterweight on
S/S (with pins)
-298.73 (-117.61) 1820 (4013) -967 (-2132) 2787 (6145)
Reference Only
