TMS800E SERVICE MANUAL INTRODUCTION
1
GROVE
Published 01-29-2014, Control # 496-00
Add: 1814 kg (4000 lb) counterweight on
carrier deck (with pins)
473.43 (186.39) 1820 (4013) 1533 (3379) 288 (634)
Add: 2722 kg (6000 lb) counterweight on
S/S (with pins)
-298.73 (-117.61) 2727 (6013) -1449 (-3194) 4176 (9207)
Add: 2722 kg (6000 lb) counterweight on
carrier deck (with pins)
473.43 (186.39) 2727 (6013) 2297 (5063) 431 (950)
Add: 2722 kg (6000 lb) wing cwt on S/S -
2 X 3000 lb (not roadable)
-287.66 (-113.25) 2722 (6000) -1392 (-3069) 4114 (9069)
Add: 2722 kg (6000 lb) wing cwt on deck
- 2 X 3000 lb (not roadable)
462.36 (182.030) 2722 (6000) 2238 (4934) 484 (1066)
Rigging Equipment
10.9 t (12 ton) Headache Ball (Swivel) in
stowage tray
829.84 (326.71) 258 (568) 380 (838) -122 (-270)
36 t (40 ton) Hookblock (3 sheave) - tied
to front bumper
1010.92 (398.00) 373 (823) 671 (1480) -298 (-657)
54 t (60 ton) Hookblock (5 sheave) - tied
to front bumper
1010.92 (398.00) 581 (1280) 1044 (2301) -463 (-1021)
70 t (77 ton) Hookblock (4 sheave) - tied
to front bumper
1010.92 (398.00) 578 (1275) 1040 (2292) -461 (-1017)
Rigging 170.82 (67.25) 45 (100) 14 (30) 32 (70)
Cribbing (in rear troughs) -35.56 (-14.00) 181 (400) -11 (-25) 193 (425)
Optional Equipment
Add: Air Conditioning - Carrier 716.28 (282.00) 25 (55) 32 (70) -7 (-15)
Add: Air Conditioning - S/S -82.83 (-32.61) 91 (200) -13 (-29) 104 (229)
Trailing Boom - Carrier Components -101.60 (-40) 31 (69) -5 (-12) 37 (81)
Trailing Boom - S/S Components 181.33 (71.39) 34 (75) 11 (24) 23 (51)
Trailing Boom - Boom brackets (use with
trailing boom with dolly option)
774.14 (304.78) 105 (232) 145 (319) -39 (-87)
Driver 760.60 (299.45) 91 (200) 123 (271) -32 (-71)
Substitutions, Deletions, and Removals
Sub: Main Hoist only (replace aux hoist
and cable with IPO cwt
-288.57 (-113.61) -128 (-283) 66 (145) -194 (-428)
Del: Main Hoist cable (600’ of 3/4” 6x37) -230.15 (-90.61) -283 (-624) 116 (255) -399 (-879)
Del: Aux hoist cable (607’ of 3/4” 35x7) -316.51 (-124.61) -336 (-740) 189 (417) -525 (-1157)
Sub: Aluminum Outrigger Floats 5.08 (2.00) -33 (-72) 0 (-1) -32 (-71)
Sub: Michelin Tires -17.78 (-7.00) 60 (132) -2(-4) 62 (136)
Sub: Bridgestone Tires 17.78 (7.00) 56 (124) 2 (4) 54 (120)
Sub: Optional Cable on Main Hoist (607’
of 3/4” 35x7)
-230.15 (-90.61) 53 (116) -21 (-47) 74 (163)
Sub: Cummins QSM Tier 3 Off Highway
Engine
660.40 (260.00) -281 (-620) -330 (-728) 49 (108)
DESCRIPTION
CG to CL
REAR BOGIE
cm (in)
WEIGHT
kg (lb)
FRONT AXLE
kg (lb)
REAR AXLE
kg (lb)
Reference Only
