9-6
Published 01-29-2014, Control # 496-00
LUBRICATION TMS800E SERVICE MANUAL
4. Pump Drive Shaft
a. U-Joints
Lube Type - EP-MPG
Lube Interval - 250 hours
Lube Amount - Until grease extrudes
Application - 2 grease fittings
b. Spline
Lube Type - EP-MPG
Lube Interval - 500 hours
Lube Amount - Until grease extrudes
Application - 1 grease fitting
5. PTO Clutch
Lube Type - HYDO
Lube Interval - 500 hours or 3 months
Lube Amount - Capacity - 650 ml (22 fl.oz.)
Application - Fill until oil weeps from side port.
6. Drive line
Lube Type - EP-MPG
Lube Interval - 500 Hours or 16,093 km (10,000 mi)
whichever interval occurs first
Lube Amount - Until grease extrudes
Application - 1 grease fittings
7. Power Steering Gearbox
Lube Type - EP-MPG
Lube Interval - 1000 hours
Lube Amount - Until grease extrudes
Application - 1 grease fitting
8. Steering Relay Arms
Lube Type - EP-MPG
Lube Interval - 250 hours
Lube Amount - Until grease extrudes
Application - 2 grease fittings
9. Front Aluminum Wheel Pilots
Lube Type - ASC
Lube Interval - When wheels are removed for service.
Lube Amount - Generously coat the wheel pilot or hub
pads with anti-seize (ASC) compound. Do not apply
anti-seize compound to the face of the wheel of the hub.
Application - Brush on
10. Front Axle Hubs
Lube Type - SSGL-5
Lube Interval - Check fluid level every 250 hours and
refill as necessary.
Lube Amount - 0.95 l (1.0 qt)
Application - Fill to the oil level mark on the housing with
the fill plug and the oil level mark horizontal.
11. Front Axle Tie Rod Ends
Lube Type - EP-MPG
Lube Interval - 1000 hours
Lube Amount - Until grease extrudes
Application - 4 grease fittings
12. Front Axle King Pins
Lube Type - EP-MPG
Lube Interval - 1000 hours
Lube Amount - Until grease extrudes
Application - 8 grease fittings
13. Front Axle Brake Slack Adjusters
Lube Type - EP-MPG
Lube Interval - 1000 hours
Lube Amount - Until grease extrudes
Application - 4 grease fittings
14. Front Axle Brake Camshafts
Lube Type - EP-MPG
Lube Interval - 1000 hours
Lube Amount - Until grease extrudes
Application - 4 grease fittings
CAUTION
Axle fluid levels shall be adjusted to bottom of fill plug
threads. Check with crane on level ground, at its normal
ride height, cold or room temperature oil only.
Reference Only
