marposs Merlin - Basic Devices

- 14 -
The following is a list of devices that can be connected to Merlin.
Whatever type of device is selected, it is necessary to enter a customized name in
the related field
• M1 Wave: Marposs Bluetooth
®
buffers with electrical capsules (see par. 2.3.1)
• I-Wave: Marposs Bluetooth
®
buffers with mechanical capsules (see par. 2.3.1)
• MultiWave: Marposs multisection buffers with Bluetooth
®
interface. Manages up to
7 measurement channels, excluding the optional heat sensor (i.e. a maximum of 6
channels if the system is also fitted with the heat sensor) (see par. 2.3.1)
• Easy Box U1AIR: 1 pneumatic input
• Easy Box U3AIR: 3 pneumatic inputs
• Easy Box U4AIR: 4 pneumatic inputs
• Easy Box U4H: for Marposs standard half-bridge/HBT transducers (see par. 2.3.5)
• Easy Box U4D: Mitutoyo Digimatic compatible
• Easy Box U4T: half-bridge/HBT compatible with Tesa amplifiers
• Easy Box U4F: for Marposs standard full-bridge/LVDT transducers
• Easy Box U8IO: 8 digital Input/Output lines
• Easy Box U4P: push button for remote control and data acquisition (see par. 2.3.2)
• Easy Box U4M: “MG” 4 HBT transducers interface
• Easy Box U4TP_E: for type-E thermocouples
• Easy Box U4TP_J: for type-J thermocouples
• Easy Box U4TP_K: for type-K thermocouples
• Easy Box U4TE: for “Trac” tranducers
• Easy Box U4E: 3 inputs for incremental transducers (see par. 2.3.3)
• Easy Box U4F-HR: for Marposs standard full-bridge/LVDT transducers with
sub-micron resolution
• Easy Box U4S: 4 serial devices (see par. 2.3.4)
• Digi Crown: Marposs digital network for various devices (see par. 2.3.6)
• Serial gauge: devices equipped with RS232 interface (see par. 2.3.7)
• Vectrix DR-200R: wireless system to connect various devices (see par. 2.3.8)
2.2 Basic devices
NOTE: If it is necessary to connect more than 5 Easy Boxes to the Merlin,
use a HUB USB with its own power supply (7 USB ports: D-Link DUB
H7, 4 USB ports: LINDY Smart Hub Pro powered - code 4701300468).
As reported in the operating limits table (paragraph 1.1) the limit of
connectable sensors is 16 and then is possible connect up to 4 devices
which can manage 4 sensors, (i.e. EasyBox U4F, U4Air...), 5 devices which
can manages 3 sensors (i.e. EasyBox U3Air or U4E) up to 8 devices which
can manage one sensor (EasyBox U1Air, iWave, M1Wave...); it is possible
to connect up to 7 channels Bluetooth
®
working simultaneously.
