On some devices it is necessary to set up additional configuration parameters, as
well as the name.
Box fitted with 4 push-buttons, used for remote control and data acquisition. Each
input may be defined as N
ORMAL or COMMUTATIVE, these two modes differ as follows:
• N
ORMAL: this button is activated by pressing it, and deactivated releasing it.
• C
OMMUTATIVE: the button remains active even after it is released and must be
pressed again in order to deactivate it.
Easy Box with 3 inputs for incremental or absolute type, rotary or linear encoders,
with analogue or digital interfaces.
• E
XTERNAL POWER SUPPLY: The U4E requires its external power supply unit when
the current consumption of the connected encoders is over 200 mA.
The Easy Box U4S is recognized automatically by the system, so that no set-up is
required. The programming of these inputs is handled within the parameters of the
S
ERIAL GAUGE.
2.3 Devices with additional parameters
2.3.2 Easy Box U4P
2.3.3 Easy Box U4E
2.3.4 Easy Box U4S
2.3.1 M1Wave, I-Wave e MultiWave
NOTE: Only one Easy Box U4S may be connected to Merlin.
NOTE: The maximum number of Bluetooth® devices that may be con-
nected to Merlin is 16, and up to 7 of these may be accessed simulta-
neously.
Tap BINDING to execute interfacing/pairing with a M1 Wave, I-Wave
or MultiWave plug
Configurable parameters:
• A
CQUISITION SPEED: data acquisition speed (Options: SLOW 10 sample/second,
F
AST 40 sample/s, MEDIUM 20 sample/s, default: MEDIUM).
• B
ATTERY TYPE: select the battery type of the Wave plug (Options: ALKALINE, NI-
M
H, LI-ION, default: ALKALINE).
• B
ATTERY WARNING LEVEL: the system provides the battery level indication
(Options: 05%, 10%, 25%, 40%, 60%, 85%, default: 25%).
• T
URN OFF TIME (SEC): the plug switches itself off if it is inactive for a given period
(default: 1200 sec, minimum = 30, maximum 28800 = 8 hours)
