- 6 -
Access to sub-menu where it is possible to change the LANGUAGE
Access to MEASUREMENT DEVICES MAP page where it is possible to insert
additional devices (See chapter 2)
Access to I/O LINES MAP page that provides a rapid overview of all the
I/O signals associated with the connected devices (See paragraph
2.7).
Access to LIST OF SERIAL PROTOCOLS page that lists all the standard pro-
tocols handled by Merlin and enables the user to create customised
protocols (See chapter 7).
Access to MAIN SETUP page (See chapter 6).
Access to TRACING DATA (See chapter 8).
Access to software function which enables the BACKUP RESTORE of the
application (See Chapter 10).
Display the MERLIN VERSION, ALLOCATED MEMORY and FREE SPACE REMAINING
ON DISC.
1.4.1 Settings menu
