marposs Merlin - Tracing Data Request TAB

- 29 -
3.2.2 Tracing data request TAB
This programming page enables the tracing parameters, and defines the way for
requesting such information to the operator. T
RACING parameters are additional
runtime data that the operator can/has to input; these data are saved and linked
with the measurements acquired. Up to ten parameters can be enabled and for
each one must be defined if the operator is forced to input a value (M
ANDATORY) or
can skip it (O
PTIONAL). The values can be input on operator request or at the end of
a measure sequence (after the last step).
To insert the T
RACING DATA it is necessary that one BATCH is activated.
Define the number of measurement steps by tapping STEP.
