8 TRACING DATA
This phase is used to define the data that can be used to trace the production by
tapping the T
RACING during the measurement phase.
8.1 Pre-defined data
The following table contains a list of pre-defined data, in text form if their value is free
or Catalog form if their value has to be selected from a pre-defined list (the Catalog
corresponding to the specific datum). Catalog type data must contain at least one
value before they can be used.
N° TRACING
D
ATA
PARAMETER
CORRESPONDING
Q-DAS
K-
FIELD
DEFAULT SETTINGS
TYPE BEHAVIOUR
1SERIAL NUMBER K 0006 TEXT EVENT
2CAVITY K 0007 CATALOG*STATE
3GAGE K 0012 CATALOG*STATE
4MACHINE K 0010 CATALOG*STATE
5OPERATOR K 0008 CATALOG*STATE
6PART IDENT. K 0009 TEXT EVENT
7REASON OF TEST K 0015 CATALOG*STATE
8ORDER K 0053 TEXT STATE
9EVENT K 0005 CATALOG*EVENT
10 CUSTOM TEXT K 0009 TEXT EVENT
11
P
RODUCTION
NUMBER
K 0016 TEXT STATE
12
W
ORK PIECE
FIXTURE
K 0017 TEXT STATE
During the measurement phase, the tracing information request is split into 2 tabs:
the N.9 Event datum is used automatically for the events tab, whereas all the other
data are used for the tracing tab.
NOTE: The Q-DAS catalogue may only contain the keys that are listed in
the above table, if it is necessary to use Q-Das keys that are not included
in the table, please contact the nearest Marposs office.
