WRS – Installation Manual
4.2 WRP60 - Assembling the Transmitter
WARNING
When fitting the probe, make sure that the seal rings are in very good conditions and correctly
positioned in their own seat.
Proceed as follows for fitting or removing the probe on/from the transmitter:
• Screw the probe (B1) to the transmitter (A1) using the wrench supplied.
After completing the operation, it is necessary to align the system (see section 4.4 on page. 27)
Figure 4-3. Fitting the probe - WRP60 transmitter.
