WRS – Installation Manual
31
4.7.2 Version with central screw
• Use the screw (A) to fasten the flange (B) to the machine table (Figure 4-18).
Figure 4-18
• Fasten the WRTS on the flange with the 4 screws (D) without tightening them (Figure 4-19).
Figure 4-19
After completing the operation, it is necessary to align the system (see section 4.7.3 on page 34).
D
D
B
A
