WRS – Installation Manual
4.15.5 Manual activation menu (ACT)
This function makes it possible to manually activate the WRP - WRTS transmitter and put it in the measuring
cycle, in order to test the system. The outputs towards CNC are all safe. This function is useful for testing the
system. It is possible to exit this modality only waiting for the time T set in the WRI receiver programming
menu to expire (2 minutes if T“- -“ is set).
Figure 4-63. ACT menu
The following is a detailed description of the ACT Menu:
Should there be more than one probe paired, you have the possibili
ty of selecting which probe
WRP_WRTS transmitter is to be activated “A”, “B”, “C” and “D”.
