WRS – Installation Manual
82
Transmitter
WRP - WRTS
LED flashing, state: “#1
error” See Table 4-7.
Malfunction of the probe
Contact the service dept.
LED flashing, state: “#2
error” See Table 4-7.
Transmission module
malfunction
LED flashing, state: “#3
error” See Table 4-7.
T25P measurement head
malfunction.
LED flashing, state: “#4
error” See Table 4-7.
• Inappropriate User set:
• Unsuitable forward speed;
• Stylus materials;
• Stylus length.
Poor repeatability
• Stylus or shear pin loosened
or damaged.
• Correctly screw the stylus
or replace it (see section
4.2.2).
• Taper shank connection
loose or not aligned.
• Repeat the system
alignment followed by a
calibration.
• Probe calibration not
performed.
•
Perform a calibration
cycle with the machine
tool.
Should the tests give a negative result contact the service dept.
