Maytag MDE25PN - Dryer Gas Specs

3-8

Anti-Rattle Clip
Ignitor
Gas Regulator
Blower Housing
Thermal Fuse
FOUND BEHIND THE FRONT PANEL
Behind
Display Lens
User Interface
The components and their locations are shown below.
COMPONENT ACCESS
COMPONENT LOCATIONS
Flame Sensor
High-Limit
Thermostat
Gas Burner
Rear Drum Rollers
Drive Motor
Exhaust Thermistor
Belt Switch (Mounted
On Drive Motor Bracket)
Central Control Unit
Electric Heater
Assembly
Thermal Cutoff
High-Limit
Thermostat
Heater Element
Belt & Drum
Thermal Cutoff
Assembly
UIC Transformer
Console
Light Lens
Keypad
Belt Switch (Mounted
On Drive Motor Bracket)
Drum Clip, Plug or Hole in Rear
Speed Increaser With Belt Located
Between Motor & Blower Housing
Rear Bulkhead
Ignitor
Rear Drum Rollers
10
220-240V~50Hz 1ph 3A max. IP24 Clothes capacity: 9.0 kg max.
European Country: CH, CZ, CY, ES, GB, GR, HR,
IE, IT, PT, SI, SK, TR
0.562703 m
3
/hr
30 mbar
37 mbar 30 mbar
28-30 mbar
N/A N/A
N/A
N/A
N/A
7.4 mbar 7.4 mbar
20 mbar
20 mbar
25 mbar
20 mbar
0.562703 m
3
/hr
II
2H3+
II
2H3B/P
II
2H3+
I
2E+
II
2H3B/P
AT, CH, CY, CZ, DK, EE, FI, GR,
HU, IT, NO, RO, SE, SK, TR
AT, CH, CY, CZ, DK, EE, FI, GR,
HU, IT, NO, RO, SE, SK, TR
CH, CZ, CY, ES, GB, GR, HR,
IE, IT, PT, SI, SK, TR
European Gas Category:
Gas Flow Rate:
Supply Pressure (G20):
Factory Adjusted Pressure:
European Country:
European Gas Category:
Butane Supply Pressure (G30):
Adjusted Pressure:
Adjusted Pressure:
Propane Supply Pressure (G31):
Factory set for NATURAL GAS: Injector size: 2.2 mm Heat input gross: 5.9 kW
With LP Gas Conversion Kit: Injector size: 1.25 mm Heat input gross: 6.4 kW
With France/Belgium NATURAL GAS conversion kit: Injector size: 1.65 mm Heat input gross: 5.9 kW
FR, BE
European Country:
European Gas Category:
Supply Pressure (G20):
Supply Pressure (G25):
Adjusted Pressure:
NOTE: Conversion kit : From Natural Gas to LP Gas : Whirlpool Part No. W10233219.
Manufacturer : Whirlpool Corporation, Benton Harbor, Michigan 49022, USA.
Conversion kit : From Natural Gas to Natural Gas - France/Belgium: Whirlpool Part No. W10184947.
