Maytag MDE25PN - Remove Dryer Side Panel (Left Side Shown)

4-32
Remove dryer drum (See page 4-22).
Remove rear panel (See page 4-31).
Remove the 1/4” hex head screw in lower
front left corner of dryer.
Remove two 1/4” hex head screws from
lower back edge of side panel, one from the
corner in to the base and one above that in
to rear bulkhead.
1.
2.
3.
4.
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.

Two 1/4” Hex
Head Screw
1/4” Hex
Head Screw
Support side panel and lift rear bulkhead
and move it forward to release hook from
the back edge of the side panel.
Lay side panel down while continuing to
support rear bulkhead.
To completely remove side panel, lift base of
dryer to release two tabs of the side panel
from two slots in the base.
5.
6.
7.
Hook On Rear
Bulkhead
Two Tabs In
Two Slots
