4-15
To remove door handle after door halves
are separated (See page 4-13). Remove 3
star head screws.
Use a flat blade screwdriver to press in on
plastic tab on the inside of the door handle.
Pull handle away from the door.
1.
2.
3.
Separate door halves (See page 4-13).
Remove door handle (See left column on
this page).
Rotate inner lens slightly to release tabs
that secure the inner lens to the front door
half and lift lens out of door trim.
1.
2.
3.
3 Star Head
Screws
