4-14
Remove four star head screws that secure
the hinge to the door.
Move hinge to other side and attach it with
four screws just removed. There are two
placement pins in the hinge that fit into two
holes for correct hinge placement.
Install hinge screw hole covers where
hinge was removed from. Align two pins on
back of cover with two holes for the door
hinge screws. Press pins into holes as far
as they will go.
10.
11.
12.
Rotate outer door 180° to place handle on
the opposite side of hinge location.
Place inner door into outer door with hinge
opposite the handle side.
Reinstall 6 star head screws in the door.
The longest screw goes in the hole
at the top of the door. These screws have
high and low threads for holding in plastic.
13.
14.
15.
Handle
Hinge
4 Star Head
Screws
Hinge Hole
Covers
To Next Page
