AUTOMATIC TRANSAXLE SPECIFICATIONS
id050000100300
End Of Sie
Item Specifications
Transaxle type AW6A-EL, AW6AX-EL
Gear ratio
1GR 4.148
2GR 2.370
3GR 1.555
4GR 1.154
5GR 0.859
6GR 0.685
Reverse 3.393
Final gear ratio 3.462
AT F
Type JWS3309
Capacity (approx. quantity)
7.0 {7.4, 6.2}
(L {US qt, Imp qt})
Torque converter stall torque ratio 1.97
Hydraulic system
(Number of drive/driven plates)
C1 clutch 7/7
C2 clutch 4/4
C3 clutch 4/4
B2 brake 7/6
Band servo
(mm {in})
Servo diameter (piston outer dia./retainer
outer dia.)
61.3/66.0
{2.41/2.60}
Front planetary gear
(Number of teeth)
Ring gear 81
Sun gear 45
Pinion gear 17
Rear planetary gear
(Number of teeth)
Ring gear 72
Middle sun gear 33
Rear sun gear 27
Long pinion gear 18
Short pinion gear 17
Counter drive gear (Number of teeth) 50
Counter gear (Number of teeth)
Driven gear 51
Drive gear 15
Ring gear (Number of teeth) 53
