AUTOMATIC TRANSAXLE [AW6A-EL, AW6AX-EL]
05-17–3
05-17
AUTOMATIC TRANSAXLE CROSS-SECTIONAL VIEW [AW6A-EL, AW6AX-EL]
id051723101900
End Of Sie
C2 CLUTCH C1 CLUTCH C3 CLUTCHB2 BRAKE B1 BRAKE
ONE-WAY
CLUTCH
COUNTER
DRIVE GEAR
COUNTER GEAR
(DRIVEN)
DIFFERENTIAL
TORQUE
CONVERTER
COUNTER GEAR
(DRIVE)
