AUTOMATIC TRANSAXLE SHIFT MECHANISM
05-18–3
05-18
Up Switch
Outline
• The up switch detects an up-shift operation in the M range and sends an up-shift request signal to the TCM.
Operation
• The up switch is an on/off type switch that turns on when the selector lever is in the M range (+) side position.
UP SWITCH
ac9uun00000329
