CONTROL SYSTEM
07-40–17
07-40
Control Table
• The full-auto air conditioner system functions based on the five basic types of controls and two supplementary
functions.
×:Possible
-:Not possible
Control Type Transition by Switch Operation (Front)
Airflow temperature control, airflow volume control
*1
: Adjusted up or down in increments of 0.5 within a range of 15.0—32.0.
*2
: Increases to the manual voltage that is closest to the auto voltage.
Basic control Control description Correction control Front Rear
Airflow temperature control Airflow temperature automatic
control
MAX HOT and MAX COLD correction ××
Air mix actuator opening angle correction ××
Airflow volume control Airflow volume automatic control Warm-up correction ××
Mild start correction ××
MAX HOT and MAX COLD correction ××
Defroster correction × -
Solar radiation correction × -
Airflow volume manual control Defroster correction × -
Airflow mode control Airflow mode automatic control Warm-up correction × -
MAX HOT and MAX COLD correction ××
Airflow mode manual control ⎯×-
Air intake control Air intake automatic control MAX HOT and MAX COLD correction × -
Defroster correction × -
Air intake manual control Defroster correction × -
A/C compressor control A/C compressor automatic
control
MAX HOT and MAX COLD correction × -
Defroster correction × -
A/C compressor manual control Defroster correction × -
Supplementary function
Fail-safe function
On-board diagnostic function
Operation switch
Airflow
temperature
control
Airflow volume control
Control prior to
switch operation
Control prior to switch operation
Automatic control Automatic control
Defroster
correction
Manual control
1234567
OFF switch Automatic control OFF OFF OFF
AUTO switch Automatic control Automatic control
*6 *6
Fan switch
+ Automatic control
Manual control
*2
Manual control
*7
2345677
- Automatic control
Manual control
*3
Manual control
*8
1123456
MODE switch Automatic control Automatic control
*5
No change
DEFROSTER switch Automatic control Defroster correction
*5
Defroster correction
A/C switch Automatic control Automatic control No change No change
REC switch Automatic control Automatic control No change No change
Driver-side
temperature
setting dial
*1
15.0 MAX COLD MAX HI No change No change
15.5—31.5 Automatic control Automatic control No change No change
32.0 MAX HOT
AUTO HI
*4
No change No change
Passenger-
side
temperature
setting dial
*1
15.0 Automatic control MAX HI No change No change
15.5—31.5 Automatic control Automatic control No change No change
32.0 Automatic control
AUTO HI
*4
No change No change
DUAL switch Automatic control
*6
No change No change
