CONTROL SYSTEM
07-40–19
07-40
Control Type Transition by Switch Operation (Rear)
Airflow temperature control, airflow volume control
*1
: Adjusted up or down in increments of 0.5 within a range of 15.0—32.0.
*2
: Set to the rear airflow volume control dial position.
*3
: Set to the driver-side temperature setting dial position.
*4
: Warm-up correction takes precedence.
*5
: MAX HOT and MAX COLD correction takes precedence.
*6
: Operable only when the rear control switch is on and the control indicator is illuminated.
End Of Sie
NG: TARGET TEMPERATURE
TARGET TEMPERATURE OUTLINE
id074000105800
Features
• The front climate control unit calculates the target temperature (temperature to stabilize set temperature) based
on input from each sensor and the temperature control dial to control each actuator, the blower motor and A/C
compressor.
End Of Sie
Operation switch
Airflow temperature
control
Airflow volume control Airflow mode control
Control prior to
switch operation
Control prior to switch operation
Control prior to
switch operation
Automatic control Automatic control Manual control Automatic control
R
E
A
R
Fan switch OFF Automatic control - OFF
Fixed at mode before
turned OFF
Fan switch Automatic control -
*2
Automatic control
Temperature
setting dial
*1
MAX
COLD
MAX COLD - No change Automatic
Middle Automatic control - No change Automatic
MAX HOT MAX HOT - No change Automatic
F
R
O
N
T
OFF switch Automatic control OFF OFF
Fixed at mode before
turned OFF
AUTO switch
*6
Automatic control Automatic control No change Automatic control
Fan switch Automatic control Automatic control No change Automatic control
DEFROSTER switch Automatic control Automatic control No change Automatic control
Temperature
setting
dial
*1, 6
15.0 MAX COLD MAX HI No change Automatic control
15.5—31.5 Automatic control Automatic control No change Automatic control
32.0 MAX HOT
AUTO HI
*4
No change Automatic control
Rear control switch: ON Automatic control
*2
- Automatic control
Rear control switch: OFF
*3,*5
-
*5
Automatic control
