117
No ow: channel
S-113, S-123, S-133,
S-143, S-153, S-163,
S-173
This report occurs for the following channels:
• Air • Suction • Elevator
• Biopsy • Jet
• Extra • Water
Action: First try the process step again by pressing the Start
button. If the report recurs, press the
Stop
button.
Cause: Channel connector not connected.
Action: Press the Stop
button and connect the endoscope. Start the program again.
Cause: The connector terminal block handle is not connected, or the block is out of alignment.
Action: Press the Stop
button and open the cover. Place the terminal block and make sure that the
handle is fastened in the lock pins on both sides. Start the program again.
Cause: An incorrect program choice was selected for the instrument.
Action: Check that the number of channel connections (excluding the leak test) agrees with the statement
on the screen after “Parameter set.” In the case of an anomaly or doubts, stop the program and
report the error directly to the system manager.
Cause: Wrong block.
Action: Check that the number of hoses on the block (excluding the leak test) is the same as the number
of channel connections on the endoscope. In the case of a deviation, replace the block with the
correct implementation and start the program again.
Cause: Too little pump pressure or the channel sensor is faulty.
Action: Consult the maintenance department. After restart, the channel sensor does not become high.
Press the F1 or F2 buttons to see the signal units.
Cause: The sprayer is worn, which causes too much pressure (ow) loss along the bearing.
Action: A horizontal spray pattern of the leaking water can be seen with a restart. Report the error to
the maintenance department.
Cause: The channel sensor is out of alignment.
Action: After restart the signal blinks too much and is unstable. Press the F1 button to signal units.
Report the situation to the maintenance department for carrying out calibration.
