Module and Program Status
The status of each module is indicated in the main section of the screen. Program operations for the left
module are on the left side of the screen; operations for the right module are on the right side of the screen.
Running program operations for each module are indicated in the section. The information provided
includes:
• Operator name • Run time remaining
• Endoscope ID • Volume
• Program name • Temperature
• Parameter set • Program progress bar
• Number of cycles • Phase progress bar
• Program status • Step progress bar
• Expected run time • Cycle messages
Heartbeat
The red heartbeat indicator blinks on and off to show that the current program is active. Each module has
a heartbeat indicator.
Program Messages
Program messages and operator instructions are shown in the lower section of the screen. The messages
are presented with text and color. If an error occurs, an audible alarm also sounds.
The text shows the program time elapsed at which the message occurred, the message code, and a
description of the message or instructions for the operator to follow. For troubleshooting purposes, the
message codes and additional message details are listed in Chapter 5 Troubleshooting. The meaning of
each screen color is shown in Table 2:
Table 2 Screen Color and Program Status
Screen Color Program Status
1 Gray Program in standby
2 Orange Standby, with lid open or a warning is present
3 Blue Cycle in process
4 Red Error or Cycle Failed, endoscope not disinfected
5 Green
Cycle completed successfully, endoscope
disinfected
