5. Remove the Color Change/Take-Up/Feeder Assembly by removing the three cap head screws
mounting it to the upper arm assembly.
6. Measure the amount of the color change shaft that extends from the left side of the old color
change motor.
7. Turn the color change spindle on the replacement assembly until it is the same as the replacement
assembly.
8. Mount the replacement Color Change/Take-Up/Feeder Assembly to the upper arm body loosely.
9. Align the base of the Color Change/Take-Up/Feeder Assembly to the outline traced on the upper
arm body from the old assembly and tighten the screws to The torque specications.
10. Install the needlecase assembly.
11. Check and adjust the needlecase alignment as necessary using the procedures specied in
“Needlecase Alignment Procedures”.
