Monthly
Lubrication Point(s) Lubrication Used
X-Drive Rails HP Grease
Y-Bearing Blocks Sewing Machine Oil
X-Cable Tension (Test)
Grabber Eccentric HP Grease
Quarterly
Lubrication Point(s) Lubrication Used
Take-Up Lever Cam, Presser Foot Cam Follower, &
Right Needle Bar Guide
HP Grease
Presser Foot Cam & Left Needle Bar Guide HP Grease
Thread feed Rollers and Pinch Rollers EMB Grease
Yearly
Lubrication Point(s) Lubrication Used
Wide Angle Driver HP Grease
The following belts should be checked once a year: Y-Axis Timing Belt, and Z-Drive Belt. You can either
have a Service Technician check these belts for a charge, or you can perform these checks yourself. To
perform these checks, you will need to purchase the following tools / xtures and follow the procedures
in this Technical Manual.
• Fixture, Y-Belt Tensioning (PN: 32108)
• Force Gauge (0-10 lbs.) (PN: 995591-01)
• Universal Force Gauge Adapter (PN: 32498) see Y-axis timing belt Tensioning , Z-drive Belt
Tensioning sections
•
CAUTION!! Some of the lubrication procedures instruct you to remove the right/left front cov-
ers. Do not turn the machine off, then on again when either of these covers is removed. This
will cause the machine to color change, which will cause the needle bars to fall out. Do not
move the needlecase at all when either of the front covers is removed. If you proceed without
this cover damage to your machine will occur and a service call will be necessary.
•
Disclaimer: The manfacturer will not be held responsible for any damage to the machine from
not performing this step.
