Laser Pointer Assembly
•
WARNING!! This procedure is intended to be performed only by specially trained service techni-
cians and personnel. Disassembly by untrained individuals will void any warranty protection and
can result in personal injury or damage to the machine.
•
WARNING!!! DO NOT allow the laser beam to be aimed at yours or anyone else’s eyes. The la-
ser emits a very concentrated light beam that can cause permanent blindness. Use extreme care
in handling the laser assembly to make sure it is not going to be inadvertently aimed at some-
one’s eyes or face. DO NOT LOOK DIRECTLY AT THE LASER LENS WHILE IT IS ENERGIZED!
Replacement Parts Needed:
• 1 inch laser assembly
Replacing the laser assembly:
1. Color change to Needle 1 and then engage the E-stop button.
•
WARNING!! DO NOT proceed past this point until the e-stop button has been engaged. Failure
to do so can cause personal injury or damage the machine.
Figure 1 Laser Assembly Installed
