Explanation of Machine Symbols
These labels are placed on the machine at specied locations to warn you of certain machine hazards.
Caution!!
Indicates a machine component will move. Keep clear!
Shock Hazard. No user replaceable parts behind this label. Do not open!
Moving gears. Keep clear!
Vertical Pinch Point. Keep clear!
Horizontal Pinch point. Keep clear!
Needle Pinch point. Keep clear!
