Special Tools and Fixtures
The following xtures and special tools are required to perform certain procedures and repairs described
in this manual:
• Fixture, Y-Belt Tensioning (PN: 32108)
• Force Gauge (0-40 lbs.) (PN: 995595-01)
• Force Gauge (0-10 lbs.) (PN: 995591-01)
• Universal Force Gauge Adapter (PN: 32498)
• Head Timing Dial Indicator Gauge (PN: 32453-01)
• Head Timing Adaptor Fixture (PN: 33065)
• 3 lb. Weight (PN: 32434)
• Hook Retaining Finger Gauge (PN: 009027-01)
• Take-Up Lever Timing Fixture (PN: 32413)
• Needle Depth Fixture (PN: 32650)
• Fixture, Z Home Flag (PN: 32980)
• Pin, Gauge, Thread Feed Gear (PN: 32996)
• Gauge, Height, Take-Up Lever (PN: 33017)
• 12 Gram Weight (PN: 10082)
• Metric Ruler
• Feeler Gauge Set
All of the above xtures can be ordered through the manufacturer.
It is strongly recommended that the xtures recommended in this manual are used. Making adjustments
without the proper tools and xtures can result in poor performance or damage to the machine. The ma-
chine is dependent on proper maintenance and adjustment in order to produce high quality embroidery.
