187 of 271
Figure 5 - LED Cluster Harnesses Connected at Main PCB
12. Replace all twist-lock cable ties that were removed from the harnesses.
13. Replace the EMI cover carefully.
14. Install the right upper arm front cover and tighten the screws to the torque specications.
15. Install the remaining covers in the reverse order that you removed them and tighten the screws to
the torque specications.
16. Turn the machine ON and verify that the LEDs come on in the right LED cluster assembly.
