Size Min Max Min Max
M5 24 29 2.7 3.3
M6 40 48 4.5 5.5
M8 80 97 9 11
Zn Plated, Property Class 8.8, Low Prole Socket Head Screws
PN: 30750-XX
M4 23 28 2.61 3.19
Black Oxide, Property Class 10.9, Flat Head Socket Screws (PN: 001935-XX, 007443-XX)
M3 15 19 1.73 2.11
Zn Plated, Property Class 10.9, Flat Head Socket Screws (PN: 011197-XX, 011198-XX)
M4 34 40 3.77 4.61
M5 65 78 7.29 8.91
Zn Plated, Property Class 12.9, Flanged Socket Head Screws (PN: 30790-XX)
M4 40 48 4.45 5.45
Stainless Steel, Property Class 10.9, Button Head Cap Screws (PN: 011161-XX, 011162-XX, 011163-XX)
M3 15 19 1.73 2.11
M4 34 40 3.77 4.61
M5 65 78 7.29 8.91
Zn Plated, Property Class 04, Metric Hex Nuts (PN: 680430-XX) (Torque based on screws they attach to)
M4 23 28 2.6 3.2
M5 46 56 5.2 6.3
Machine Specic and Custom Hardware
Self Tapping Plastic
DURO Screw (PN:
30737-01)
8 10 0.9 1.10
M6 Lock Nut (PN:
005284-01)
Install nut until it makes contact with the spring washer, then turn nut another
half turn.
M4x0.7 Nylock Nut
(PN: 003573-04)
No torque specication for this nut. Turn nut until specied belt tension is
achieved.
